The MCM112 ECU kit provides everything required for a complete replacement of the factory ECU on a range of Mercury outboard engines. The kit includes a knock sensor and knock control system, offering a significant advantage over the factory ECU.
The all-in-one ECU and adaptor unit installs quickly and easily, enabling total and instant control of all tuning parameters within minutes. Fine tune your engine for maximum power and economy or add modifications, such as Injectors, Supercharger Pulleys, NOS and Fuel Changes.
The MCM112 integrates with Mercury dash and throttle systems* and seamlessly connects with MoTeC Displays and other MoTeC accessories. It utilises the existing wiring, fuel system, ignition and sensors** and is equally suited to single or multi-engine installations.
Along with fuel, ignition, throttle and drive trim control, this kit also supports other OE ECU features, including;
- Key Start Via OE CAN
- Full dash functionality including warnings and run time for maintenance
- Integration with multi engine boats via CAN
- Stern Leg Position Monitoring
- Multi Engine Synchronisation
The supplied start file contains all calibrations and settings for the sensors, port fuel injectors, ignition coils, knock control, throttle servo and cruise control. It has also been calibrated to match the OE factory fuelling and ignition. This saves a significant amount of time as it shortcuts the setup process.
The ECU fully integrates with other MoTeC products and provides pre-defined CAN messaging for all current Display Loggers, Loggers, LTCs, GPS and BR2.
The Mercury Outboard 112 (MCM112) Package includes Level 2 Logging as standard.
*Not compatible with Mercury Joystick control and the independent steering Skyhook feature.
**Humidity Sensor not supported.
